BYG22D-TR

ultrafast avalanche SMD rectifier, 200V 25NS, DO-214AC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.08~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.08~0.10

PartNumber:: BYG22D-TR

Brand:: Vishay Telefunken - Vishay | Pack: DO | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Kelly Huang's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-24

From Other Seller

Part Number:BYG22D-TR
US $0.08 - 0.10
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BYG22D-TR is a ultrafast avalanche SMD rectifier of vishay general semiconductor. The package of this device is DO-214AC (SMA). It is feature with low profile package. When concerned with the application, it is widely used in high frequency rectification and freewheeling, as well as application in switching mode converters nd inverters for consumer, computer, automotive and telecommunication.

Parametrics

Absolute maximum ratings:(1)Device marking code: BYG22D; (2)Maximum repetitive peak reverse voltage, VRRM: 200V; (3)Average forward current, IF(AV): 2.0A; (4)Peak forward surge current 10 ms single half sine-wave superimposed on rated load, IFSM: 35A; (5)Pulse energy in avalanche mode, non repetitive (inductive load switch off), I(BR)R = 1 A, TJ = 25 °C, ER: 20mJ; (6)Operating junction and storage temperature range TJ, TSTG: -55 to +150°C.

Features

Features:(1)Low profile package; (2)Ideal for automated placement; (3)Glass passivated junction; (4)Low reverse current; (5)Low forward voltage; (6)Soft recovery characteristic; (7)Ultra fast reverse recovery time; (8)Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C; (9)Solder dip 260 °C, 40 s; (10)Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC.
