MC331694

support IC, GaAs Power Amplifier Enhanced FET, TSSOP, 9.5 V, Low Startup, low Operating Current

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~5.00

PartNumber:: MC331694

Brand:: Motorola, Inc - Motorola | Pack: TSSOP | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Kelly Huang's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-08

From Other Seller

Part Number:MC331694
US $0.50 - 5.00
P103W

US $15.00 - 22.00 / Piece
(0) Remove
D1028UK

US $75.00 - 81.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MC331694 is a support IC for GaAs Power Amplifier Enhanced FETs used in hand–held telephones such as GSM and PCS. This device provides negative voltages for full depletion of Enhanced MESFETs as well as a priority management system of drain switching, ensuring that the negative voltage is always present before turning on the Power Amplifier. Additional features include an idle mode input and a direct drive of the N–Channel drain switch transistor. The MC331694 is available in a 4.0 V version intended for control of the RF Power Amplifier in GSM, DCS1800 and PCS applications.

Parametrics

MC331694 absolute maximum ratings: (1)Power Supply Voltage VCC: 9.5 V; (2)Tx Power Control Input VTx: VCC V; (3)Idle Mode Input Vi: VCC V; (4)Sense Input VSense: -5.0 to 0 V; (5)Negative Generator Output Source Current ISS: 20 mA; (6)Charge Pump Capacitor Current Imax: 60 mA; (7)Diode Forward Current IFmax: 60 mA; (8)Gate Drive Output Current IGO: 5.0 mA; (9)Operating Ambient Temperature TA: –40 to +85 ℃; (10)Storage Temperature Range Tstg: –60 to +150 ℃.

Features

MC331694 features: (1)Negative Regulated Output for Full Depletion of GaAs MESFETs; (2)Drain Switch Priority Management Circuit; (3)CMOS Compatible Inputs; (4)Idle Mode Input (Standby Mode) for Very Low Current Consumption; (5)Output Signal Directly Drives N-channel FET; (6)Low Startup and Operating Current.
