Product Summary
The PQ05RF21 is a 2A Output, Low Power-Loss Voltage Regulator. The PQ05RF21 is a series power supply for various electronic equipment such as VCRs, electronic munic instruments.
Parametrics
PQ05RF21 absolute maximum ratings: (1)Input voltage VIN: 35V; (2)Output current IO: 2 A; (3)Power dissipation (No heat sink) PD1: 1.5 W; (4)Power dissipation (With infinite heat sink) PD2: 18 W; (5)Junction temperature Tj: 150 ℃; (6)Operating temperature Topr: -20 to +80 ℃; (7)Storage temperature Tstg: -40 to +150 ℃; (8)Soldering temperature Tsol: 260 (For 10s) ℃.
Features
PQ05RF21 features: (1)Low power-loss (Dropout voltage : MAX. 0.5V; (2)Compact resin full-mold package.; (3)Built-in ON/OFF control terminal (PQ05RF2/PQ05RF21 series); (4)Built-in output voltage minute adjustment terminal.
Diagrams
 |
