Product Summary

The SN74LS191N is a synchronous, reversible up/down counter having a complexity of 58 equibalent gates. The SN74LS191N is a 4-bit binary counter. Synchronous operation is provided by having all flip-flops clocked simultaneously so that the outputs change coincident with each other when so instructed by the steering logic. This mode of operation eliminates the output counting spikes normally associated with asynchronous counters.

Parametrics

SN74LS191N absolute maximum ratings: (1)supply voltage, VCC: 7 V; (2)input voltage: 7 V; (3)operating free-air temperature: 0 to 70℃; (4)storage temperature range: -65 to 150℃.

Features

SN74LS191N features: (1)counts 8-4-2-1 BCD or binary; (2)single down/up count control line; (3)count enable control input; (4)ripple clock output for cascading; (5)asynchronously presettable with load control; (6)parallel outputs; (7)cascadable for n-bit applications.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74LS191N
SN74LS191N
Texas Instruments
Counter ICs 4-Bit Sync Up/Down
Data Sheet
0-1: $0.60
1-25: $0.54
25-100: $0.47
100-250: $0.42
SN74LS191NE4
SN74LS191NE4
Texas Instruments
Counter ICs 4-Bit Sync Up/Down
Data Sheet
0-1: $0.60
1-25: $0.49
25-100: $0.44
100-250: $0.39
SN74LS191NSRG4
SN74LS191NSRG4
Texas Instruments
Counter ICs Sync 4B Up Down Counters
Data Sheet
0-1400: $0.28
1400-2000: $0.26
2000-5000: $0.25
5000-10000: $0.24
SN74LS191NSRE4
SN74LS191NSRE4
Texas Instruments
Counter ICs 4-Bit Sync Up/Down
Data Sheet
0-1400: $0.28
1400-2000: $0.26
2000-5000: $0.25
5000-10000: $0.24
SN74LS191NSR
SN74LS191NSR
Texas Instruments
Counter ICs 4-Bit Sync Up/Down
Data Sheet
0-1400: $0.28
1400-2000: $0.26
2000-5000: $0.25
5000-10000: $0.24
