Product Summary
The PS12015 is an Intelligent Power Module suitable for Acoustic noise-less 1.5kW/AC400V Class 3 Phase inverter and other motor control applications.
Parametrics
PS12015 absolute maximum ratings: (1)VCC, supply voltage: 900V; (2)VCC(surge), supply voltage (surge): 1000V; (3)VP or VN, each output IGBT collecotr-emitter static voltage: 1200V; (4)VP(s) or VN(s), each output IGBT collector current: ±15A; (5)IC (ICP), brake IGBT collector current: 5 (10) A; (6)IF (IFP), brake diode anode current: 5 (10) A.
Features
PS12015 features: (1)3-Phase IGBT inverter bridge configured by the latest 3rd. generation IGBT and diode technologies; (2)Circuit for dynamic braking of motor regenerative energy.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 PS12015 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
PS12015-A |
|
MOD IPM 3PHASE IGBT 1200V 15A |
Data Sheet |
Negotiable |
|
||||
