M48T08-150PC1

8 K x 8 non-volatile static RAM and realtime clock, DIP, 1W, 20mA, –0.3 to 7V, 28-lead

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.50~6.00

PartNumber:: M48T08-150PC1

Brand:: STMicroelectronics - ST | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Kelly Huang's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-05

From Other Seller

Part Number:M48T08-150PC1
US $2.50 - 6.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The M48T08-150PC1 is an 8 K x 8 non-volatile static RAM and realtime clock which is pin and function compatible with the DS1643. The monolithic chip is available in two special packages to provide a highly integrated battery-backed memory and real-time clock solution. The M48T08-150PC1 provides sockets with gold-plated contacts at both ends for direct connection to a separate SNAPHAT housing containing the battery and crystal. The unique design allows the M48T08-150PC1 to be mounted on top of the SOIC package after the completion of the surface mount process. The SNAPHAT housing is keyed to prevent reverse insertion.

Parametrics

M48T08-150PC1 absolute maximum ratings: (1)TA, Ambient operating temperature: 0 to 70℃; (2)TSTG, Storage temperature (VCC off, oscillator off): –40 to 85℃; (3)TSLD, Lead solder temperature for 10 seconds: 260℃; (4)VIO, Input or output voltages: –0.3 to 7 V; (5)VCC, Supply voltage: –0.3 to 7 V; (6)IO, Output current: 20 mA; (7)PD, Power dissipation: 1 W.

Features

M48T08-150PC1 features: (1)Integrated ultra low power SRAM, real-time clock, power-fail control circuit, and battery; (2)BYTEWIDE. RAM-like clock access; (3)BCD coded year, month, day, date, hours, minutes, and seconds; (4)Typical clock accuracy of 亇1 minute a month, at 25℃; (5)Automatic power-fail chip deselect and write protection; (6)Software controlled clock calibration for high accuracy applications; (7)Self-contained battery and crystal in the CAPHAT. DIP package; (8)Packaging includes a 28-lead SOIC and SNAPHATR top (to be ordered separately); (9)SOIC package provides direct connection for a snaphat top which contains the battery and crystal; (10)Pin and function compatible with DS1643 and JEDEC standard 8 K x 8 SRAMs; (11)RoHS compliant; (12)Lead-free second level interconnect.
