Product Summary
The Mobile Intel QG82943GML SL9Z9 Express Chipset comes with the Generation 3.5 Intel Integrated Graphics Engine, and the Intel Graphics Media Accelerator 950 (Intel GMA 950), providing enhanced graphics support over the previous generation Graphics and Memory Controller Hubs ((G)MCH’s).
Parametrics
QG82943GML SL9Z9 absolute maximum ratings: (1)Die Temperature under Bias 0 to 105 ℃; (2)Storage Temperature -55 to 150 ℃; (3)VCC: -0.3 to 1.65 V; (4)VTT (FSB Vccp): -0.3 to 1.65 V; (5)VCCSM: -0.3 to 1.90 V; (6)VCC3G: -0.3 to 1.65 V; (7)VCCA_3GBG: -0.3 to 2.65 V; (8)VCCA_CRTDAC: -0.3 to 2.65 V; (9)VCC_SYNC: -0.3 to 2.65 V; (10)VCCHV: -0.3 to 3.65 V.
Features
QG82943GML SL9Z9 features: (1)Supports single-/dual-channel DDR2 SDRAM; (2)Maximum Memory supported: up to 4 GB at 400, 533 and 667 MHz; (3)64-bit wide per channel; (4)Three Memory Channel Configurations supported:; (5)Single-Channel; (6)Dual-Channel Symmetric; (7)Dual-Channel Asymmetric; (8)One SO-DIMM connector per channel; (9)256-Mb, 512-Mb and 1-Gb memory technologies supported; (10)Support for x8 and x16 devices; (11)Support for DDR2 On-Die Termination (ODT); (12)Enhanced Addressing support (XOR and Swap); (13)Intel Rapid Memory Power Management (Intel RMPM); (14)Dynamic row power-down; (15)No support for Fast Chip Select mode; (16)Support for 2N timings only; (17)Supports Partial Writes to memory using Data Mask signals (DM).
Diagrams
 |
